Honeywell MP909D1219 Pneumatic Damper Actuator, Spring Return, 3 Square Inch Diaphragm, 8-13 PSI Spring Range, Barb Fitting for 3/32" OD Tubing Air Connection, 2.4" Stroke, 3/8" Threaded Shaft, 50-140 Degree Temperature Range, 5-95% RH Humidity Range
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Fedex ground and freight. Free Shipping on everything!
Honeywell MP909D1219 Pneumatic Damper Actuator, Spring Return, 3 Sq...
Description
Description
MP909D is used for pneumatic proportional control of variable volume terminal units and small dampers. Available in various operating ranges, for either individual or sequence operation with other actuators. Compatible with all competitors products.
Features:
Rugged ribbed aluminum body.
Low-friction shaft bearing.
Close tolerance on operating range and stroke.
Protected barb connector.
Versatile mounting and connecting hardware options.
Positive leakproof seal.
Product Specifications:
Manufacturer: Honeywell
Manufacturer Part Number: MP909D1219
Item: Linear Pneumatic Actuator
Dimensions (in.): 6 5/16 in. long ( add 1 in. for shaft ) x 2 13/32 in. diameter
Dimensions (mm): 160 mm long ( add 25 mm for shaft ) x 61 mm diameter
Operating Humidity Range (% RH): 5 to 95% RH
Max. Air Pressure: 30 psi
Nominal Spring Range: 8 to 13 psi
Stroke: 2-2/5"
Includes: Actuator only. 3/8 in.-16 Threaded Shaft. No Mounting Bracket or Ball Joint
