Intermatic AG2403C3 120/240 VAC Surge Protection Types 1 & 2 50 kA Surge Protector

The AG Series Surge Protective Devices (SPD) are designed for a variety of applications. Trusted, state-of-the-art TPMOV® (Thermally Protected Metal Oxide Varistor) surge protection technology eliminates the potentially hazardous failure modes that are commonly associated with standard MOV technology. A green LED indicator provides status of protection. Type 1 applications include outdoor installations before service entrances and utility meter cabinets. Type 2 applications include installations after service entrances. Outdoor applications include irrigation equipment, farm equipment, pumps, lighting fixtures, traffic signaling devices, HVACR controls and motors. AG2401C3/AG48013/AG6503C3/AG6503L3 are UL Listed to ANSI/UL 1449, 3rd edition. AG2083C3/AG4803C3/AG2403C3 are CSA certified to ANSI/UL 1449, 3rd Edition.

Features:

Six modes of protection
TPMOV® surge protection technology
Green LED protection indicator
Type 4X watertight, plastic enclosure for outdoor installations
UV-resistant polycarbonate housing
1⁄2" threaded nipple for 7⁄8" nominal conduit knockout
1-year product warranty
CSA certified to ANSI/UL 1449 5th edition

Specifications:

Manufacturer: Intermatic
Manufacturer Part Number: AG2403C3
Product Type: Surge Protector
Voltage Rating: 120/240 VAC
Surge Protection Type: 1, 2
No. of Phase: 3
Modes of Protection: 6 (L1-N, L2-N, L3-N, L1-L2, L1-L3, L2-L3)
Maximum Continuous Operating Voltage (L1-L2): 420 V
Maximum Continuous Operating Voltage (L1-L3): 300 V
Maximum Continuous Operating Voltage (L2-L3): 420 V
Maximum Continuous Operating Voltage (L1-N/G): 150 V
Maximum Continuous Operating Voltage (L2-N/G): 270 V
Maximum Continuous Operating Voltage (L3-N/G): 150 V
Nominal Discharge Current: 20 kA
Maximum Surge Current Rating Per Phase: 50 kA
Voltage Protection Rating (L1-L2): 1500 V
Voltage Protection Rating (L1-L3): 1200 V
Voltage Protection Rating (L2-L3): 1500 V
Voltage Protection Rating (L1-N/G): 700 V
Voltage Protection Rating (L3-N/G): 700 V
Voltage Protection Rating (L2-N/G): 1000 V
Enclosure: Indoor/outdoor type 4X
Wiring Configuration: Wire leads
Operating Temperature: -31 to 185 Degrees F
Dimensions: 3.5" x 6.0"x 3.5"
Weight: 2.0 lb.
