Laars Heating Systems R2015700 24 VAC 5.0 A 7 Seconds Ignition Timing Ignition Control Module

Specifications:

Manufacturer: Laars Heating Systems
Manufacturer Part Number: R2015700
Product Type: Ignition Module
Input Voltage Rating: 24 VAC
Input Frequency Rating: 50/60 Hz
Input Current Rating: 350 mA
Valve Voltage Rating: 24 VAC
Valve Current Rating: 5.0 A
Ignitor Electrical Rating: 120 VAC, 5.0 A
Ambient Temperature Rating: -40 to 164 Degrees F
Pre-purge Timing: 15 Seconds
Interpurge Timing: 15 Seconds
Post-purge Timing: 30 Seconds
Ignition Timing: 7 Seconds
Heat-up Timing: 20 Seconds
Dimensions: 9.8" x 6.65" x 2.35"
Weight: 3.0 lb.
