Ranco A30-185 42" SPST Adaptable Constant Differential Control
Description
Description
Features:
Laser-welded stainless steel bellows
Fixed or adjustable temperature settings
High-amperage contacts
Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements
Constant On or Off positions available
Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts
Standard 1/4” quick-connect terminals with optional screw terminals
Specifications:
Manufacturer: Ranco
Manufacturer Part Number: A30-185
Product Type: Adaptable Constant Differential Control
Capillary Length: 42"
Normal Off: 5.5 Degrees F
Normal On: 21 Degrees F
Warm On: 36 Degrees F
Differential: 15.5 Degrees F
Switch Type: SPST
Dimensions: 7.25" x 7.0" x 2.7"
Weight: 2.0 lb.
