Watts F315130 N240 Series, 1" NPTF Female Connection, 112 PSI Max, T&P Relief Valve

This automatic reseating temperature and pressure relief valve has a 1 inch NPT female inlet, 1 inch NPT female outlet, 6 inch stainless steel extension thermostat, pressure relief setpoint of 150 psi, and temperature relief setpoint of 210 degrees F. This valve can be installed in hot water outlet within the allowable distance from the top of the tank for commercial applications to provide protection for hot water supply tanks and hot water heaters. It features a bronze body, tamper resistant bonnet screws, and test lever. Includes a nonrestrictive discharge drain line flood sensor with SentryPlus Alert® technology to detect excessive water discharges from the relief valve. Sensor activation requires purchase of an activation kit which can be connected to existing building management systems or the Watts Cellular Gateway.

Features:
Features a flood sensor with SentryPlus Alert technology to detect excessive water discharges from the relief valve
Requires purchase of activation kit to activate sensor
Bronze Body
Tamper resistant bonnet screws
6 Inch thermostat length
Non-mechanical seat to disc alignment
Set pressure 150 psi

Specifications:

Manufacturer: Watts
Manufacturer Part Number: F315130
Product Type: Relief Valve
Body Material: Bronze
Inlet Connection Size: 1"
Inlet Connection Type: Female Threaded
Inlet Thread Type: NPTF
Lead Free: NO
Maximum Temperature: 210 Fahrenheit
Maximum Working Pressure: 112 PSI
Outlet Connection Size: 1"
Outlet Connection Type: Female Threaded
Outlet Thread Type: NPTF
Pressure Relief Setting: 150 PSI
Protection Type: Temperature And Pressure
Series: N240
Temperature Relief: 210 Fahrenheit
Thermostat Material: Stainless Steel
Thermostat Probe Length: 6"
Dimensions: 3.85" x 16.9" x 3.15"
Weight: 2.89 lb
