Aaon ASM01686 Refrigerant System Module

The AAON ASM01686 is a Refrigerant System Module (RSM) designed for use in commercial HVAC systems. This module plays a critical role in managing refrigerant flow and system diagnostics, ensuring optimal performance in large-scale applications.

Features:

Compressor Control: Manages Variable Frequency Drive (VFD) compressor operations.
Expansion Valve Modulation: Adjusts expansion valves to regulate refrigerant flow.
Condenser Fan Control: Controls condenser fan speed for efficient heat rejection.
System Monitoring: Monitors system parameters and performance.
LCD Display: Features a 2x8 character LCD display with four navigation buttons.
Alarm System: Includes an alarm system for fault detection.
E-BUS Communication: Supports E-BUS communication for system integration.
Power Supply: Operates on 24VAC power.
Refrigerant Compatibility: Designed for use with R-410A refrigerant.
System Scalability: Supports up to four RSMs in a system, depending on size.

Specifications:

Manufacturer: Aaon
Manufacturer Part Number: ASM01686
Product Type: Refrigerant System Module
