ABB 1SVR740010R0200 Time Relay

The CT-MFS.21P is a multifunction electronic time relay from the CT-S timer range. It provides 10 timing functions with 10 time ranges from 0.05 s to 300 h. This time relay operates with a rated control supply voltage of 24 - 240 V AC / DC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. Two control inputs work with volt-free (floating) triggering.The CT-MFS.21P offers the possibility of connecting a remote potentiometer for the fine adjustment of the time delay. The second of the c/o contacts can be selected as an instantaneous contact. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers maintenance free Easy Connect Technology with push-in terminals.

Specifications:

Manufacturer: ABB
Manufacturer Part Number: 1SVR730030R3300
Product Type: Time Relay
Voltage Rating: 24-240 V AC/DC
Frequency Rating: 50/60 Hz
Time Range: 0.05 Seconds to 300 Hours
Terminal Type: Screwless Terminals
Dimensions: 0.88" x 3.37" x 4.08"
Weight: 0.29 lb.
