Fireye FX04-1 Servo Motor With Quick Disconnect Connectors

Specifications:

Manufacturer: Fireye
Manufacturer Part Number: FX04-1
Product Type: Servo Motor With Terminal Block
Actuating Time For 90 Degrees Angle Of Rotation: 30 Seconds
Nominal Torque: 3 lb.-ft./ 4 Nm
Holding Torque: >3 lb.-ft./ 4 Nm
Max. Revolutions On The Output Drive Shaft: 100 Degrees
Nominal Voltage: 24 VDC~± 10%
Nominal Power Consumption: 5 VA Nominal, 7.5 VA Peak
Angle Of Rotation Limited By: Software
Degree Of Protection: NEMA 4 IP 65 (Note 1)
Installation Position: Any
Working Temperature Range: -4 Degrees F to 140 Degrees F
Duty Cycle: 100%
Dimensions: 9.3" x 11.05" x 9.15"
Weight: 3.96 lb.
Includes: Quick Disconnect Connectors
