Robertshaw 780-715 Non-lockout Ignition Module For Flame Rectification

The Robertshaw 780-845 lockout ignition control provides 90 seconds of spark, followed by a six minute time delay (purge) between ignition attempts. If the pilot flame is not sensed after three tries, the control goes into a one-hour lockout period. At the end of the lockout period, if the demand for heat is still present, the unit will repeat the three tries for ignition.

Features:

Reduces truck stock inventory, saving space and money
Easy-to-install with complete in-depth installation instructions
Pilot and main valves draw 1 Amp at 0.5 power factor
Combined load at 1.5 Amps at 0.4 power factor
95% relative humidity noncondensing at 104°F

Specifications:

Manufacturer: Robertshaw
Manufacturer Part Number: 780-715
Series Application: Intermittent Pilot Ignition Control, Nonlockout
Electrical Rating: 24V AC
Spark Rate: 3-4 per second
Maximum Total Current Load: 1.5 Amps
Flame Failure Re-Ignition Time: 0.8 seconds
Safety Lockout Timing: NA
Thermostat Anticipator Setting: 0.7 Amps
Temperature Range: -40°F to 175°F
Flame Sensor Current: 0.7mA DC @ 25°C
Transformer: 24V AC, 20VA
Control Voltage: 50/60 Hz
