Siemens Building Technology GJD221.1U 120 VAC, 50/60 Hz, Spring Return Function, 2-Position Control Signal, Electronic Fire and Smoke Damper Actuator
Have a question? Our team is here to help! Chat with us or call us: 806-763-9323 / If you need Next Day Shipping, call us!
Delivery and Shipping
Delivery and Shipping
Fedex ground and freight. Most parts ship same day and arrive within two days.
Siemens Building Technology GJD221.1U 120 VAC, 50/60 Hz, Spring Ret...
Specifications:
Manufacturer: Siemens Building Technology
Manufacturer Part Number: GJD221.1U
Product Type: Damper Actuator
Actuator Type: Electronic Fire and Smoke
Actuation Style: Rotary
Control or Fire/Smoke Type: Fire/Smoke Control Damper
Electronic Fusible Link (EFL): YES
Plenum or Standard Rating: Standard
Torque: 20 Pounds-Inches
Fail Safe: Yes
Spring Return Function: Yes
Control Signal: 2 Position
Positioning Time: 30 Seconds (Operating), 15 Seconds (Closing/Power Loss with Spring Return)
Position Feedback: No
Power Consumption: 10 VA/5 W (Running), 5 VA/3 W (Holding)
Ambient Temperature - Operation: 0 to 130 Degree Fahrenheit
Angular Rotation: 95 Degrees
Supply and Operating Voltage: 120 VAC
Frequency: 50/60 Hertz
Auxiliary Switch: No
Cable Length: 3
Housing Material: NMEMA 1, Plenum-Rated Plastic
Dimensions: 11" x 8.1" x 3.35"
Weight: 1.78 Lb
Catalog Page
Inst. Manual
Tech Sheet
